Hydraulic Grapple Standard LARGE CAPACITY
For forestry and farming
Made from Domex 710 steel and equipped with lock valve
The trunk grapple are used to transport, load, and unload tree trunks that have been cleaned of branches and are ready for transport: They can be assembled on forestry cranes of all models and sizes.
This model of grapple is used for forestry and farming.
You get all the models LARGE CAPACITY by reducing the maximum width of opening with a more rounded shape that increases the performance of use and significally the loading volume.
For example , a grapple of 1.35 m the opening will be of 1.20m.
TECHNICAL DATA FOR REFERENCE PURPOSES
| MODEL | Weight kg |
Lift Kg |
MAX bar |
A mm |
B mm |
C mm |
D mm |
E mm |
F mm |
G mm |
SP D mm |
AREA mq |
SP C mm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| THL 30 | 58 | 1000 | 200 | 1000 | 730 | 405 | 450 | 460 | 65 | 310 | 8 | 0,146 | 8 |
| THLS 30 | 72 | 1200 | 200 | 1000 | 730 | 405 | 450 | 460 | 65 | 310 | 10 | 0,146 | 10 |
| TP 120 | 100 | 1500 | 200 | 1200 | 770 | 450 | 480 | 510 | 80 | 355 | 10 | 0,201 | 10 |
| TP 135 | 140 | 1900 | 200 | 1350 | 880 | 500 | 540 | 550 | 90 | 370 | 12 | 0,255 | 12 |
| TP 155 | 212 | 2500 | 200 | 1550 | 960 | 620 | 630 | 600 | 100 | 430 | 12 | 0,336 | 12 |
| TP 175 | 300 | 3000 | 200 | 1750 | 1100 | 680 | 710 | 670 | 130 | 490 | 15 | 0,428 | 15 |
GRAPPLE ACCESSORIES- ROTATORS FOR WOOD GRAPPLE
 |
Rotori per uso orizzontale/verticale per pinze mod. RF |
 |
Rotori ad uso pendolare per pinze mod.RP |
 |
Forcella (su misura per mod. RF) |
 |
Forcella (su misura per mod. RP) |
 |
Valvola di MASSIMA per pressioni superiori ai 200 BAR |
 |
Kit Benne per pinze modello comby |
 |
Attacco rapido (specificare modello) |
Punti di Forza:
